HRSM Explosion-Proof
XE HRSM 2000-EXP Mobile
Fog Fan - Explosion-Proof
Humidification & Cooling System
Manufactured in the USA by Jaybird Manufacturing
The Aquafog XE HRSM-2000-EXP is a mobile fogging system built around Jaybird’s high-output XE centrifugal atomizer and an explosion-proof (hazardous-duty) motor for use in classified or explosion-prone environments. Designed for industrial humidification, evaporative cooling, dust suppression, and chemical fogging, the HRSM-EXP delivers portable high-volume fog production in facilities where standard equipment is not permitted.
Unlike high-pressure nozzle systems or spinning disc foggers, the HRSM-EXP uses Jaybird’s nozzle-free centrifugal atomization technology, producing extremely fine fog while eliminating clogged nozzles and high-pressure pumps.
The explosion-proof motor is rated for Class I, Group D and Class II, Groups F & G hazardous locations.
Explosion-proof units must be connected using properly rated explosion-proof electrical utilities, including both the male plug and matching female receptacle.
Using a standard non-rated plug, receptacle, or power connection will defeat the explosion-proof protection of the unit.
Jaybird offers an optional explosion-proof male plug for the unit power cord; however, the receiving female receptacle and all associated electrical components must also be properly rated and supplied by the customer or qualified contractor.
The HRSM-EXP includes an 18-gallon integrated supply tank, rugged wheeled chassis, and 4-position pivoting fogging head. Water flow is regulated by a quarter-turn ball valve and the system can be operated continuously or automated using a secondary hazardous-duty controller (where applicable).
Part of the Mobile XE Atomizer Family
- HRSM (XE HRSM-2000)
- HRSM-EXP (XE HRSM-2000-EXP) – {This Model}
- CRSM (XE CRSM-2000)
- ORSM (XE ORSM-2000)
The XE platform represents our largest atomizer class, designed for maximum coverage and industrial-scale output.
cooling, humidification, and chemical fogging
Performance Highlights
- Fogging Output: Up to 13.5 GPH
- Evaporative Cooling Capacity: 109,350 BTU/hr
- Explosion-Proof (Hazardous-Duty) Motor
- Conduit Fittings (Hazardous Location Setup)
- Pivoting Fogging Head (4-Position)
- 18-Gallon Tank w/ Float Valve Control
- Nozzle-Free Centrifugal Atomizer
- 25' Power Cord & Fittings
- Starting at $3,769.00
Optional: SST Stainless Plumbing for oxidizers and sterilization chemicals
Also available for stationary hazardous-duty applications:
XE Explosion-Proof
Mobile XE Configuration Comparison
Compare Mobile XE models to choose the right control style and application fit for your facility.
| Feature | [XE] HRSM | [XE] HRSM-EXP | [XE] CRSM | [XE] ORSM |
| Purpose | Humidification | Hazardous Locations | Chemical Fogging | Odor Control / Chemical Injection |
| Control Type | Ball Valve | Ball Valve | Timer + Auto Shut-Off | Smart Control + Auto Shut-Off |
| Max. Output | 13.5 GPH | 13.5 GPH | 9.0 GPH | 8.0 GPH |
| Bottom Feed Pump | No | No | Yes | No |
| Tank Agitation | No | No | Yes | No |
| Inlet Port for Metering Pump | No | No | Yes | Yes |
| Hazardous-Duty | No | Yes | No | No |
| Best For | Humidity / Cooling | Classified Areas | Pesticides | Odor Control & Sterilization |
All mobile fog systems ship freight and arrive fully assembled.
Hazardous-Location Humidification & Cooling Applications
The Jaybird XE HRSM-2000-EXP is engineered for facilities requiring explosion-proof humidification and evaporative cooling in classified or hazardous environments where volatile vapors, combustible dust, or other ignition risks may be present. Using Jaybird’s nozzle-free centrifugal atomizer technology, the HRSM-EXP produces ultra-fine fog and strong air propulsion while avoiding the nozzle clogging and high-pressure maintenance associated with typical misting systems.
cooling, humidification, and chemical fogging
Typical applications include:
- Hazardous-location humidification
- Dust suppression in explosion-prone environments
- Evaporative cooling in classified areas
- Industrial processing facilities with volatile vapors
- Mines and underground mines
- Military hangars and aerospace facilities
When explosion-proof equipment is required, the HRSM-EXP provides a rugged, self-contained mobile platform with industrial-scale fog output for demanding environments.
- Click to ViewFeatures
- Click to ViewSpecifications
- Click to ViewCertifications
- Click to ViewAccessories
Features & Controls
HRSM-EXP units include an internal feed pump, a manual 1/4-turn flow control valve, and an internal float valve to maintain proper tank water level during operation. Controls are simplified to meet explosion-proof requirements, with no integrated On/Off switch.
- 1/4-turn flow control valve
- In-line strainer
- Internal float valve (automatic water level control)
- Large tank access lid
- Garden hose connection
The manual ball valve allows operators to adjust fogging output based on the application. Lower feed rates generally produce a drier, finer fog, while higher feed rates increase output volume for broader coverage.
Flow Control Guide
| Valve Position | Typical Use | Fog Character |
|---|---|---|
| Full Open | Evaporative cooling, greenhouse cooling, concrete curing, mushroom growing | Highest output / heavier fog |
| Mid Open | General humidification, horticulture, wine barrel storage, wood/lumber/paper applications | Balanced output / general-purpose fogging |
| Slightly Open | Textile humidification, dust suppression, static control, lighter treatment applications | Drier / finer fog |
Control Tip: Start with a lower valve setting and increase flow only as needed. This helps maintain finer fog quality and reduces excess wetting.
Drainage Port
A specially engineered drainage port at the base of the motor allows condensation to escape, helping prevent internal moisture buildup while preserving the motor’s explosion-proof integrity.
- Extends motor life
- Made in USA
Flexible Cable
Optional flexible cord packages are available for installations requiring mobility or non-rigid connections.
- Extra hard usage rated
- STOW yellow jacket (660V, 60°C)
- UL / CSA / MSHA / RoHS compliant
| Unit Dimensions: |
Width 21 in / 53 cm Length 25.5 in / 65 cm Height 44 in / 112 cm |
| Approximate Unit Weight: | 88 lbs / 39.9 kg |
| Shipping Weight: | 138 lbs/ 62.6 kg |
| Shipping Dimentions: | 46”x 24”x 32” (LxWxH) |
| Fogging Head Pivot Angle: | 0°, 15°, 30°, 45° |
| Propulsion Distance: | 30 - 35 ft / 9.1 - 10.5 m |
| Main Motor: | 1/2 HP - 7.8 amps @ 115V 60Hz |
| Noise @ 10 ft: |
72 dB(A) |
| Average Particle Size: |
5-10 microns @ low volume 20 microns @ mid volume 25 microns @ high volume |
| Max. Fogging Output: |
13.5 GPH |
| Tank Capacity: | 18 US gal / 68 L |
| CFM: | 3,000 |
| Cooling Capability: | 109,350 Btu/h |
| 304 Stainless Steel: |
All hardware, sheet steel and |
| Environment: |
Endures temperatures from Indoors / outdoors Humidity to 85% RH UV stabilized & impact resistant |
| Country of Origin: |
USA |
ABB explosion-proof motors used on the HRSM-EXP are UL and CSA approved for the following hazardous locations:
- Class 1, Group D locations containing volatile gases such as Gasoline, Hexane, Naphtha, Benzene, Propane, Alcohol, etc.
- Class 2, Group F & G locations containing dust such as (F) Carbon Black, Coal or Coke Dust or Group (G) Flour, Starch, or Grain Dusts.
-
Hazardous Duty Plug - 125VThis high-quality plug can be used with the HRSM-EXP to allow for mobility. Only use in conjunction with a hazardous duty receptacle.
- NEMA 5-20P configuration
-
UL & CSA Approved
-
Temperature-Humidity MeterIdeal for monitoring environments up to 95% Relative Humidity
The Handheld Thermo-Hygrometer provides accurate, real-time measurement of ambient temperature and relative humidity, making it a valuable tool for monitoring greenhouse and industrial environments where fogging systems are in use.
With fast response time and reliable performance in high-humidity conditions, this unit helps operators verify system output, track environmental changes, and maintain optimal conditions for plant health and process control.
Dual readout LCD displays temperature and humidity simultaneously in °F or °C.
- Temperature range/accuracy: 32 to 122°F (0 to 50°C) / ±1.8°F (1°C)
- Humidity range/accuracy: 20 to 95% RH / ±3%
- Response time: approximately 60 seconds
- Power source: CR2032 lithium battery (included)
-
Temperature-Humidity Meter w/ Dew PointIdeal for applications up to 100% Relative Humidity
This precision hand-held thermo/hygrometer is ideal for measuring and monitoring ambient and dew point temperatures and relative humidity in a wide range of professional and industrial applications. Dual readout LCD displays in °F or °C.
- Temperature range/accuracy: -4 to 122°F (-20 to 50°C)/1.8°F (1°C)
- Humidity range/accuracy: 0 to 100%RH /3%
- Response time: 60 seconds
- Power source: Two "AAA" batteries (included)
